Modular Construction
USG Structural Panels are a developer's answer to a unique modular construction. The panels are high-strength reinforced concrete panels for use in noncombustible construction. These concrete panels are made with aggregates including glass fiber, making it as strong, but lighter than precast or poured concrete. USG Structural Panels are as easy to install as wood sheathing and provide a new, faster, easier and more efficient way to build floors, roofs and walls.
When you are looking for panels that are:
- Noncombustible
- Nonrotting
- Moisture-, mold- and termite-resistance
- Dimensionally stable
When you need to have:
- A fast installation (three easy steps: lay, fasten, finish)
- No pouring, no setting, no curing
- An alternative to poured, precast or CMU block
Roof System
- Removes steps to a finished roof
- Great uplift strength
- Membranes can adhere directly to the panels
Typical applications:
- Low-slope or steep-slope roofs
- Balconies
- Decorative soffits
- Canopies
The USG Structural roof system consists of steel joists, trusses or framing members and USG Structural Panel Concrete Roof Deck. This Roof Deck serves as a structural substrate for direct-, mechanically- or adhesive applied roof systems. The result is a noncombustible, mold-, moisture- and termite-resistant, and dimensionally stable roof deck, suitable for low-slope or steep-slope roof systems.
Build a lighter, faster roof system.
- USG Structural Panel Concrete Roof Deck
- USG Structural Panel Concrete Roof Deck High Performance Applications (English) – SCP68
- PER-14076 - Evaluation Report for USG Structural Panel Concrete Roof Deck
Subfloor System
- Great shear diaphragm and uniform load capacities
- Moisture-, mold- and termite-resistant
- Factory-manufactured, quality-controlled structural floor
- Lightweight, no curing
The USG Structural floor system consists of steel joists, trusses or framing members and USG Structural Panel Concrete Subfloor applied with mechanical fasteners. The result is a noncombustible, mold-, moisture-, termite-resistant and dimensionally stable floor assembly, suitable for a variety of floor finishes. Great shear diaphragm and uniform load capacities
Build a lighter, faster floor system.
Wall Systems
- Load-bearing capacities (axial and shear)
- Moisture-, mold- and termite-resistant
- Thinner profile and faster installation than other panelized Systems
The USG Structural wall system consists of USG Structural Panel Concrete Subfloor (for wall application) screw attached to load-bearing steel studs. The result is a noncombustible, mold-, moisture- and termite-resistant, and dimensionally stable, shear- and axial-load-bearing, fire-rated wall system.
Build a lighter, faster shear-wall system.
Additional Resources
- USG Structural Panel Concrete Subfloor Submittal Sheet (English) - SCP3
- USG Structural Panel Modular Application Sell Sheet (English) - SCP31
- USG Structural Panel Concrete Roof Deck Submittal Sheet (English) - SCP35
- USG Structural Panel Concrete Roof Deck Low-Slope Roof Application Sell Sheet (English) - SCP40
- USG Structural Panel Concrete Roof Deck Steep-Slope Roof Application Sell Sheet (English) - SCP41
- USG Modular Steel Systems Project Profile (English) – SCP72
Videos
Videos
-
Installing USG Structural Panels Concrete Subfloor
-
Top 10 Tips for Installing USG Structural Panels
-
Modular Project Profile: USG Structural Panel Concrete Subfloor
